Endoscope Camera ImagePRO-USB

SKU: ImagePRO-USB
Product Highlights:

  • 1/4" CCIQ III DIGITAL CMOS Sensor
  • Variable Focal Range Couplers Available
  • 5.0 Mega Pixel, Full HD
  • 2.0 HI-Speed USB Data Transfer
  • Driver Free
  • Focusable Video Coupler Included
  • Compact, Light Weight Body
  • Windows 10 and Mac OS (macOS) compatible!
Get help buying
Ask Our Experts
Live Chat
877.613.22.10
Product Information
The ImagePRO USB camera is a professional high resolution video device.
This camera was specially designed to work perfectly with any optical endoscope. The endoscope camera is completely portable and ready-to-use, with only one USB cable to connect it to a computer.
The light weight aluminum body houses the ¼" COLOR CMOS image sensor, which provides up to 1920 x 1080 pixels of resolution. These units feature low noise disruption of the image, even with no light illuminating the inspection area. You can view the live image on your computer or laptop without recording, or capture images or video directly to your hard drive. The live image is displayed in the viewing software (both, macOS and Windows compatible), which has an intuitive menu and features simple capture buttons.
Users are free to choose the necessary image/video capturing format for documentation of inspections.
Setting up the ImagePRO USB endoscope camera is easy with the LEMO/USB Cable (included), and a link to download viewing software will be provided upon purchase. Included focusable coupler connects the camera unit to your borescope and allows you to adjust the focus.
There is also an optional Foot Control (pedal) – which is the easiest way to turn your laptop or desktop into a capturing device. It allows you to capture images and video directly to your computer hard drive hands free, just by tapping the pedals with your foot. The Foot Control connects to your PC/laptop via a USB port, and can be set up to capture images with the main button, and to start and stop video recording with the other two. It is paired with the viewing software to work as a shortcut for buttons on your keyboard.

For Windows 10 computers: use "Camera" app to view and capture images/videos For macOS computers: use "Photo Booth" app to view and capture images/videos Contact us to download the USB camera software (Debut) for Windows 7
Specifications


  • CMOS Sensor: 1/4" CCIQ III DIGITAL QSXGA
  • Active Pixels (HxV): 2592 x 1944 / 10fps, 1920 x 1080 / 30 fps
  • Image area: 3.651 x 2.744 mm
  • Scan mode: Progressive
  • Sensitivity: 5100 e-/lux.sec
  • Dynamic range: 63 dB
  • Output format: RAW 10Bit
  • Operation Temperature : -10°C ~ 45°C
  • Cable Length: 2 meters
  • Mac OS and Windows 10 Compatible
What's included
ImagePRO-USB Camera, Video Camera Endoscope Coupler for all C-Mount type, USB Cable, User Manual.
